Circumferential Schwann cell processes often surrounding Axons or Axon sprouts
Associations
- Axon Regeneration
- Pseudo-Onion Bulb Structure
- Central: Axon(s)
- Regenerated axons & Axon Sprouts: Individual or Clusters, or
- Larger myelinated axon
- Peripheral region of Pseudo-Onion Bulbs
- Layers of Schwann cell processes
- Small, Unmyelinated axons: May be surrounded by Schwann cell processes
- Other features
- Axon Loss in nerve: Often moderate to severe
- No demyelination
- Chronic Demyelination without Remyelination
- Central: Demyelinated axon
- Peripheral: Multiple concentric Schwann cell processes
Differential diagnosis
H&E stain
|
Whorled structures: Contain nuclei & connective tissue; Myelinated axon may be in center
VvG stain
|
Beaded axon sprouts extend circumferentially around central large axon
Neurofilament stain
|
Toluidine blue stain
|
Whorled structures: Central myelinated axon is present within some pseudo-onion bulbs
Toluidine blue stain
|
Toluidine blue stain
|
Pseudo-Onion Bulbs
Around regenerated axons with thin myelin sheaths
Also present in regions with no axons
Toluidine blue stain
|
Pseudo-Onion Bulbs
Around regenerating axon clusters
Toluidine blue stain
|
Pseudo-Onion bulbs: Ultrastructure
Schwann cell processes surround central axon
From: Chunyu Cai
|
Pseudo-Onion bulbs
Multiple Schwann cell processes surround regenerated, thinly myelinated, axons
Schwann cell processes may surround collagen
Büngner Bands
Interdigitated Schwann cell processes
Collagen Bulbs
Anatomy
Collagen bulbs: Unstructured; Size 10 to 80 μM
Axons: Within some collagen clusters
Myelin: Thin; Similar thickness on all axons
Number: 0 to 5
Schwann cells: Few or Scattered small processes
Schwann cell basal lamina: Few or None
Fibroblast processes: May surround collagen clusters
Correlations
Clinical: Polyneuropathy
Anatomic pattern: Multifocal; Asymmetric
Motor + Sensory
Course: Slow progression
Nerve Size: Enlarged, Multifocfal
Electrodiagnostic
Demyelinating Features
Axon Loss: Patchy
Toluidine blue stain
|
Collagen Bulbs
Multiple clusters of endoneurial collagen: Some have myelinated axons inside
Toluidine blue stain
|
Toluidine blue stain
|
Collagen Bulbs
Multiple clusters of endoneurial collagen: Some have myelinated axons inside
From: Sara Stone
|
From: Sara Stone
|
Collagen Bulbs
Clusters of endoneurial collagen: Some have thinly myelinated axons inside
From: Sara Stone
|
From: Sara Stone
|
Collagen Bulbs
Thinly myelinated axons surrounded by collagen
From: Sara Stone
|
Collagen bulb
No associated axon
Mostly composed of collagen
Surrounded by fibroblast processes
Contains normal & large Schwann cell proceses
from: R Schmidt
|
Collagen Bulb
Central: Thinly myelinated axon
Mostly composed of collagen
Contains scattered Schwann cell proceses & nuclei
Surrounded by fibroblast processes
from: R Schmidt
|
from: R Schmidt
|
Collagen bulb
Collagen & Schwann cell processes around thinly myelinated axon
from: R Schmidt
|
Collagen Bulb
Central: Thinly myelinated axon
Mostly composed of collagen
Contains scattered Schwann cell proceses & nuclei
Surrounded by fibroblast processes
from: R Schmidt
|
from: R Schmidt
|
Collagen Bulb
Collagen & Schwann cell processes around thinly myelinated axon
from: R Schmidt
|
